T FlipFlop Rising Edge Triggered Simulator – Visual Logic Tool

4instrumentation20
T Flip-Flop with Oscilloscope Chart

Clock: LOW

Q: OFF
NOT Q: ON

Welcome to the T FlipFlop Rising Edge Simulator an interactive, real-time educational tool designed to easily understand the concept of flipflop.

Key Features:
• Interactive Controls: Toggle the input and start/stop the clock and respective result will be updated.And see how the Flip-Flop responds precisely fo type of clock signal.


• Dynamic Chart: Visualize all signals—CLK, T, Q, and ~Q—with color-coded, real-time chart that updates with each change in inputs.


• Adjustable Clock Speed: Fine-tune the clock interval with a responsive slider to observe each state transition with clarity.


• Smooth Signal Navigation: Scroll through the signal timeline with navigation buttons to go forward or backward.


• Lamp Output Indicators: Instantly see the current state of Q and NOT Q outputs through glowing lamps—green for ON, gray for OFF.
• Responsive Design: Fully optimized for both desktop and mobile browsers.

Whether you’re a student or engineer, this T FlipFlop Rising Edge Simulator brings logic gates to life in the most engaging way possible.
